| Model No. |
BN-265IP180DV2IR |
| Lens |
180 Degree 3.0 Megapixel HD Lens |
| System structure |
Embedded RTOS,dual-core 32bit DSP(Hi3516D),pure hard
compression ,watch dog |
| Sensor |
1/3" OV4689 low illumination CMOS；
color 0.01Lux@F1.2,black/white 0.001Lux@F1.2 |
| Video compression |
H.265/H.264,support dual stream,AVI;0.1M~10Mpbs
variable;1~30f/s variable |
| Image output |
Main stream:4MP 2592*1520@15fps；3MP 2048*1536@25fps
sub-stream: 1280*720,704*576 @25fps |
| Noise reduction |
Support 2D/3D |
| Wide dynamic |
Support digital |
| Audio interface |
1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up
input;1ch output,impedance:16Ω,30mw,support microphone; |
| Audio compression |
G.711,support bidrectional talk,audio&video synchronization; |
| Network interface |
1*RJ45 10/100M adaptive Ethernet port;support
RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc |
| USB interface |
1*USB,support WIFI/3G |
| Auto iris |
No |
| Singal interface |
One photo resistance interface,one IR-CUT interface ,support
photo resistance signal and IR-CUT links to IR |
| PTZ |
1*RS485,support kinds of PZT protocols |
| Alarm I/O |
2/0 (support alarm input and video link to background) |
| SD Card |
Unsupport |
| Anti-lightning |
Power anti-lightning，conform to GB/T17626.5 and
IEC61000-4-5 |
| Other function |
Support WEB,OSD,live video transmission,motion detect and IO
alarm,front-end storage/playback/download, and center
reminder and image linkage,support JPEG capture；united
remote client monitoring sofaware、MYEYE;perfect SDK |
| ONVIF |
Support |
| Mobile monitoring |
Support multiple mobile monitoring（iOS，Android） |
