| Model No. |
BN-AHD4100E1/IR |
BN-AHD4130E1/IR |
BN-AHD4200E1/IR |
| TV System |
NTSC/PAL Optional |
| Video Signal |
AHD/CVI/TVI/CVBS signal option |
| Image sensor |
1/4" CMOS |
1/3" CMOS |
1/2.8" CMOS |
| Resolution |
1.0Megapxiel |
1.3Megapixel |
2.0Megapixel |
| Pixel |
1280*720P |
1280*960P |
1920*1080P |
| Frame |
25/30 fps |
| Illumination |
0.1Lux（F2.0,AGC ON), 0 Lux with IR |
| Shutter Electoric |
1/50s~1/100,000s(PAL),1/60s~1/100,000s (NTSC) |
| IR Led |
2pcs IR Led |
| Lens |
3.6/6mm Lens Optional |
| Scanning system |
2:1 interface |
| Sync.System |
Internal Sysn |
| S/N Ratio |
>48dB (AGC off) |
>58dB (AGC off) |
>58dB (AGC off) |
| Day/Night Mode |
IR Cut Supported |
| White Balance |
Auto |
| AGC |
Auto |
Auto/Manual |
Auto/Manual |
| OSD |
YES (Up: AHD, Down: CVI, Left: TVI, Right: CVBS) |
| Noise Reduction |
NO |
3D |
3D |
| Power Supply |
DC 12V |
| Operation Environment |
–20°C~+60°C / 10%~90%RH |
| Working Humidity |
≤90% |
